Place of Origin: | Guangdong, China, Guangdong,China(Mainland) |
Brand Name: | mottcell, Mottcell |
Model Number: | 32650, IFR32650 |
Minimum Order Quantity: | 100 units |
Price: | $2.50/units >=100 units |
Packaging Details: | Packaging details:Standard export box |
Supply Ability: | 500000 Unit/Units per Month |
Detail Information |
|||
Place of Origin | Guangdong, China, Guangdong,China(Mainland) | Brand Name | mottcell, Mottcell |
---|---|---|---|
Model Number | 32650, IFR32650 | Battery Size: | 32650 |
Weight: | 145g | The Charging Ratio: | 0.5C |
The Discharge Rate: | 0.5C | Anode Material: | LFP |
Application: | Toys, Power Tools, Home Appliances, Consumer Electronics, Golf Carts, Solar Energy Storage Systems, E-bike,UPS,Mobil Charger,Lawn Light,Lamps | Type: | LiFepO4 |
Standard Voltage: | 3.2v | Size: | Diameter 32.5*Height 69.5mm |
Standard Capacity: | 6000mAh | Life Cycle: | ≥2000 Times |
Certificate: | UN38.3, IEC, UL, BIS | Warranty: | 2 Years |
Port: | Shenzhen |
Specifications
Items | Specification |
Battery Model | IFR32650-6000mAh |
Capacity | 6000mAh |
Standard Voltage | 3.2v |
Size |
Diameter:32mm Height:69mm |
Charge Current |
Standard Charge:3000mA Rapid Charge:6000mA |
Discharge Current |
Standard Discharge:3000mA Max Discharge:6000 |
End of charge voltage | 3.65v |
End of discharge voltage | 2.0v |
Weight | Approx 146G |
Storage Humidity | ≤75%RH |
Operation Temperature |
Charging:0℃-45℃ Discharging:-20℃-60℃ |
Appearance | Without scrath,distortion,contamination and leakage |
Standard Environmental Condition |
Temperature 23±5 Degree Celsius Humidity 45-75%RH Atmospheric Pressure 86-106Kpa |
Visual Inspection | There should not be any remarkable scratches,cracks,bolts,cauterization,deformations,swelling,leakage and so on the surface of the cell |
Warning |
Do not throw into fire or incinerate Do not puncture,damage and disassemble Do not mix fresh batteries with used batteries |
Certification | UL,IEC,UN38.3,MSDS,BIS |
