Place of Origin: | China |
Brand Name: | Maconini |
Certification: | CE/ROSH/MSDS/UN38.3 |
Model Number: | 3.2v 200ah |
Minimum Order Quantity: | 1 PCS |
Price: | Negotiable |
Packaging Details: | Neutral Hard Cartons, wooden box , plastic pallet |
Delivery Time: | 15 DAYS |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 1800000pcs per year |
Detail Information |
|||
Place of Origin | China | Brand Name | Maconini |
---|---|---|---|
Certification | CE/ROSH/MSDS/UN38.3 | Model Number | 3.2v 200ah |
Applications: | UPS,CCTV,SOLAR,GOLF CAR,FORKLIFT | Battery Size: | H520*W130*T79mm Or Customized |
Battery Type: | Lithium-ion | Bms: | Build-in Smart BMS |
Charg Current: | 1C | Charge Temperature Range: | -20~60℃ |
Charging Time: | 4-6 Hours | Chemistry: | Lithium Iron Phosphate (LiFePO4) |
Cycles: | 3000 CYCLES | Discharging Time: | 8-10 Hours |
Nominal Capacity: | 24Ah | Pluse Current: | 300A |
High Light: | 48v Inverter Solar Battery,GEL Inverter Solar Battery,AGM Storage Battery |
12v 24v 48v Inverter Solar Battery 100ah 200ah 250ah Rechargeable AGM/GEL Storage Batteries
rechargeable li-ion battery prismatic cell 3.2v 100ah lithium lifepo4 cell
Specification
Battery Type | LiFePO4 |
Nominal Voltage | 3.2V |
Nominal Capacity | 200ah |
Internal Resistance | ≤5mΩ |
Limited Charge Voltage | 3.65V |
Charge Method | CC/CV |
Discharge Cut-off Voltage | 2.3V |
Max. Charge Current | 1C |
Max. Continuous Discharge Current (<30min) | 3C |
Pulse Discharge Current (<3s) | 5C |
Cycle Life | > 3000 cycles |
Dimension | Thickness: 54mm |
Width: 174mm | |
Length: 207mm | |
Weight | 4220g |
Operation Temperature Range | Charge: 0~45℃; |
Discharge: -20~60℃ | |
Recommended operating temperature: 15℃~35℃ | |
Self-Discharge Rate | Residual capacity: ≤5%/month; |
Features
1. Safety: safest Li-Ion battery, CE UL approved, built-in PCM/BMS
2. Clean and Green energy, no toxic material contained
3. Long life cycle:> 3000 times, 6-8 times of lead acid battery
4. No memory effect, highly efficient, charge anytime
5. Small size and light weight: 1/2 size& weight of lead acid battery
6. Good performance at high temperature
7. Low self-discharge rate: < 5% monthly
Application
Mainly used for power tools, RC toys, small medical instruments, solar energy system, solar light, emergency light, lighting, communication equipment, UPS, small portable equipment : interphone,portable printer, small household cleaner etc.
