Place of Origin: | Guangdong, China |
Brand Name: | Mottcell |
Certification: | cb/ce/fcc/rohs |
Model Number: | lithium ion batteries |
Minimum Order Quantity: | 1000 units |
Price: | $1.50/units 1000-4999 units |
Packaging Details: | Wooden cartons |
Supply Ability: | 300000 Piece/Pieces per Day |
Detail Information |
|||
Factory Wholesale Grade A 26650 LFP 5Ah Lithium Iron Phosphate 26650 3.2v 5000mah Lifepo4 Battery Cell For LED Flashligh
CHARGE | |
Std. Charge Current | 0.2C |
Max.Charge Current | 1C |
Rec. Charge Voltage | 4.2V |
Rec. CutOff Voltage | 4.25V~4.30 V |
Std. Charging Time @0.5C | 5.2C |
Quick-Charge Time @1C | 1.0h |
DISCHARGE | |
Std. Discharge Current | 0.2C |
Max. Discharge Current | 2C |
Max.Peak Discharge Current | 3C[6s] |
Rec. Discharge Voltage | 3.00V |
Rec. Cut-Off Voltage | 2.90V~250 V |
Std. Discharging Time @0.5C | 5.0h |
GENERAL | |
Nominal Voltage | 3.2V |
Nominal Capacity | 3300mAh @0.2C |
Min.Capacity | 3280mAh @0.2C |
Energy | 10.56Wh |
Resistance | ≤m350 @50% SOC |
Self-discharge | <3% / Month |
Cycle Life @0.5C | ≥2000 times |
Dimension (D x H) | 26.1*66.2mm |
Approx.Weight | approx.85g |
Case Material | Steel |
Welding Mode | DC Spot Welding |
Welding Materials | Nickel Strap |
Swell Coefficient | 0 |
TEMPERATURE | |
Discharge Temperature | -4~140℉(-20~60℃) |
Charge Temperature | 32~113℉(0~45℃) |
Storage Temp.(One Month) | -4~113℉(-20~45℃) |
Storage Temp.(One Year) | 32~95℉(0~35℃) |
Storage Humidity | <70% |
COMPLIANCE | |
Certifications | CE.UN38.3.UL.MSDS |
* High Energy density
High-efficient charge: Charge and discharge efficiency is more than 99.8%
* Low self-discharge: After fully charged with 28 days, the battery self-discharge is less than 5%.
* No memory effect
* High-power discharge
* Good of high temperature feature
* Environmental Protection
* High Security
A: Yes, we welcome sample order to test and check quality.
A:Sample needs 15-18 days, mass production time needs 25-30 days
A: Depends on different models.For the very regular models,the MOQ is LOW
A: We usually ship by TNT, UPS, FedEx.... It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
A: Firstly,pls let us know your requirements,such as the dimension,continuous&peak discharge current ,application of the battery.
Secondly,pls let us know the purchasing quantity and when will your project start.We quote according to the details.
Thirdly customer confirms the price,sample and places deposit for formal order.
Fourthly We arrange the production.
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A: Yes, we offer 12 months warranty to our products.
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order to replace the defective.
Thirdly,we will test the defective batteries and make 8D report.We will find out the reason and propose the
improvement measures for future production.
